The electromagnet is applicable to the control circuit with DC voltage up to 220 v. as the power element of the solenoid valve connected by six-way screw, it is applied to the oil environment and equipment with high temperature and humidity。
| Model | rated voltage（V） | Rated suction（N） | Rated stroke（mm） | Full stroke（mm） | Power consumption（W） | Withstand static oil pressure（MPa） | Operating frequency（T/h） | Coil bore diameter（mm） |
|---|---|---|---|---|---|---|---|---|
| YZZ6-22YC |
12/24/110/220 |
≥22 |
2.8 |
≥6.1 |
≤30 |
16 |
12000 |
φ16 |
