Through the built-in circuit module, the low power consumption electromagnet adopts high current to drive the electromagnet action, and the small current remains absorbed, which can effectively avoid the phenomenon that the coil is burnt out due to the high temperature rise of the electromagnet caused by the stuck valve in the operation of ordinary AC products。
| Model | rated voltage（V） | Power frequency（Hz） | Rated suction（N） | Rated stroke（mm） | Full stroke（mm） | Power consumption（W） | Withstand static oil pressure（MPa） | Operating frequency（T/h） | Coil bore diameter（mm） |
|---|---|---|---|---|---|---|---|---|---|
| MFJ12-27YC（X） |
220/240 |
50/60 |
≥50 |
4 |
≥8 |
10W |
21 |
3600 |
φ22 |
