DH / k3049 double head proportional / switching electromagnet is mainly used to match with haWe load sensitive proportional multi-way valve. It is widely used in construction machinery vehicles to realize stepless speed regulation and remote control of hydraulic system actuator within the rated range。
| model | Rated current（A）,normal resistance 20℃（Ω） | Rated suction（N） | Rated stroke（mm） | Full stroke（mm） | Force hysteresis（%） | Current hysteresis（%） | Repetition accuracy（%） | Withstand static oil pressure（MPa） | Enclosure protection class | Heat resistance grade | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| DH3049 |
0.63 1.26 |
27.0 6.7 |
23 |
1.2 |
＞1.7 |
≤3 |
≤3 |
≤1 |
5 |
IP65 |
H |
| DK3049 |
24 |
34.8 |
23 |
0.7 |
＞1.7 |
- |
- |
- |
5 |
IP65 |
H |
