This product is used for rexro Ⅲ h proportional flow valve and proportional directional valve. The input current is stepless regulated within the rated range, which can realize stepless speed regulation, commutation and remote control of the actuator of the hydraulic system within the rated range。
| model | Rated current（A）,normal resistance 20℃（Ω） | Rated suction（N） | Rated stroke（mm） | Full stroke（mm） | Force hysteresis（%） | Current hysteresis（%） | Repetition accuracy（%） | Withstand static oil pressure（MPa） | Heat resistance grade | |
|---|---|---|---|---|---|---|---|---|---|---|
| GP45-4-A |
0.8 |
19.5 |
80 |
3 |
6 |
≤3 |
≤2 |
≤1 |
21 |
F |
